Ashcroft Digital Pressure Gauge, Calibrator Pressure Gauge, 14.7 to 15 psi, 3-inch Dial. 2089
4,555
6,506
Digital Pressure Gauge
- Three accuracy levels 0.05% & 0.1% and 0.25% terminal point method
- Temperature compensated from 0 to 150°F (-18-60° C)
- Includes stainless steel cover and padded carry pouch
- Battery powered
- 7 different languages
Split in 4 payments of 1138.53
monthly without fees , learn more
Split it into 4 payments of 1138.53
interest-free , learn more
Ashcroft Digital Test Gauge Features:
- Also known as lab test gauges, these Grade 5A digital gauges are the most highly accurate grade gauges available.
- With functionality that allows users to toggle between engineering units.
- These gauges are commonly used in high-precision laboratory applications where 0.05% accuracy is required.
- 12 engineering units
- Field calibration capability
- Weatherproof IP65.
- Large LCD display.
Industrial Market Applications:
- Test Bench / Gauge Repair Facilities
- Calibration Laboratories
- Mobile Calibration Labs
- Test Measurement and Validation
| Accuracy | ±0.05% |
|---|---|
| Gauge Case Material | 304 Stainless Steel |
| IP | NEMA Rating / IP65 |
| Lens Material | Polyester |
| Nominal | |
| Dial Size | 3 inch |
| Primary Range | 14.7 to 15 psi |
| Wetted Parts Material | 316 Stainless Steel |
| Process Connection Gender | Male |
| Process Connection Size | 1/4 inch |
| Process Connection Type | NPT |
| Pressure Gauge Type | Test Pressure Gauge |
| Pressure Range Type | Pressure |
| Primary Units | psi |
| Includes Calibration Certificate | 10 NIST Traceable Chart |
| Includes | Padded Carry Pouch; Stainless Steel Cover |
| Manufacturer Part Number | 2089 |
| Series | 2089 |
| Adjustable Set Points | Yes |
| Application | Laboratory; Test and Measurement |
| Auto-Shutoff | Yes |
| Auto-Shutoff Time | 2 min; 5 min; 15 min; 30 min |
| Backlit Screen | Yes |
| Bar Graph | 10 Segments |
| Battery Run Time | 1,000 hr |
| Battery Type | (3) AAA Batteries |
| Blowout Safety Back | No |
| Burst Pressure | 45 psi |
| Case Color | Silver |
| Case Depth | 1.7 inch |
| Case Diameter | 3.25 inch |
| Case Finish | Tumble Polished |
| Case Shape | Round |
| Data Update Frequency | 100 msec; 200 msec; 500 msec; 1 sec |
| Digit Height | 0.66 inch |
| Display Range | 14.7 to 15 psi |
| Display Screen Type | LCD |
| Display Units | Bar; cm H2O; ft SW; in H2O; in Hg; kg/sq cm; kPa; mBar; mm H2O; mm Hg; Mpa; psi |
| Hazardous Location Rating | Not Rated |
| Includes Batteries | Yes |
| Includes Mounting Hardware | No |
| Includes Rubber Boot | No |
| Languages | Dutch; English; French; German; Italian; Portuguese; Spanish |
| Low Battery Indicator | Yes |
| Manufacturer Warranty Length | 1 yr |
| Memory Features | Min/Max |
| Mounting Type | Stem-Mount |
| Non-Sparking | No |
| Number of Digits | 5 |
| Panel-Mountable | No |
| Peak Hold | No |
| Power Source | Battery |
| Process Temperature Range | 0° to 150°F |
| Sensor Material | 316 Stainless Steel |
| Sensor Type | Silicone MEMS |
| Socket Material | 316 Stainless Steel |
| Standards | CSA; FM Approved |
| Case Material | Stainless Steel |
| Connection Location | Bottom |
| Gauge Wetted Parts | Stainless Steel |
| Pressure Range | 14.7 to 15 psi psi |
| Process Connection | 1/4 inch NPT Male |
| Process Connection Location | Bottom |
| Test Pressure Gauge Type | Calibrator Pressure Gauge |
| With Calibration Certificate | With Calibration Certificate |
| Weatherproof | Yes |
| Weight | 0.22 KG |
| Code | BD-20Z635 |
| ID | 985702 |
