Out of Stock
An advanced desktop 3D printer high performance, remarkable accuracy and a user-friendly touchscreen interface
3D printing farms ready
- Wi-Fi, Ethernet, and USB connection
- Built-in camera
- User-friendly design of the touchscreen
- Material End Detection
- Upgraded extruder (compatible with advanced and semi-flexible filaments)
- Upgraded cooling system (double fan and extruder cooling)
- Upgraded hotend (V3) and nozzle with new geometry
- Perforated plate with pogo pins instead of a small connector
- Wide range of dedicated filaments
- External materials are applicable
| Build volume | 200 x 200 x 180 mm (7.9 x 7.9 x 7.1 in) |
|---|---|
| Material container | Spool |
| Material diameter | 1,75 mm (0.069 in) |
| Nozzle diameter | 0,4 mm (0.016 in) |
| Support | Mechanically removed – printed with the same material as the model |
| Extruder | Single (upgraded for more demanding materials) |
| Extruder cooling system | Radial fan cooling the extruder block |
| Hotend | Redesigned (v3), new geometry of the nozzle |
| Material endstop | Mechanical |
| Platform | Perforated, heated, equipped with Pogo pins |
| Connectivity | WI-FI, USB, Ethernet, |
| Operating system | Android |
| Processor | Quad Core |
| Touchscreen | 4” IPS 800 x 480 |
| Camera | Yes, 640 x 480 |
| Available materials | Z-ULTRAT, Z-HIPS, Z-GLASS, Z-PETG, Z-ESD, Z-PCABS, Z-ABS, Z-ASA Pro, Z-PLA Pro |
| External materials | Applicable |
| In the box | 3D printer, spool of material, side covers, USB flash drive, build platform, heatbed cable, power cable, spool holder, material guide, quick start guide, Z-SUITE 2 software, starter kit |
| Printing | |
| Technology | LPD (Layer Plastic Deposition) – depositing melted material layer by layer onto the build platform |
| Layer resolution | 90-390 microns |
| Minimal optimal wall thickness | 800 microns |
| Minimal wall thickness | 400 microns |
| Dimensional accuracy | +/- 0.2%** |
| Angle accuracy | +/- 0.2%*** |
| X | Y positioning accuracy / 1.5 micron |
| Z-axis single step | 1.25 micron |
| Platform levelling | Automatic measurement of platform points’ height |
| Maximum platform temperature | 105 ˚C (221 °F) |
| Maximum printing temperature (extruder) | 290 ˚C (554 °F) |
| Ambient operation temperature | 20 – 30 ˚C (68 – 86 °F) |
| Storage temperature | 0 – 35 ˚C (32 – 95 ˚F) |
| AC input | 110 V ~ 5.9 A 50/60 Hz 240 V ~ 2.5A 50/60 Hz |
| Power supply parameters | 24 V DC @ 14 A, 500 W |
| Maximum power consumption | 320 W |
| Weight | 26 KG |
| Code | 3D-01-0002 |
| ID | 2432463 |
