Hydraulic Cylinder, Steel, Stroke 6.250 Inch, Capacity 25 ton C256C

Name: Hydraulic Cylinder, Steel, Stroke 6.250 Inch, Capacity 25 ton C256C
SKU: C256C
Price: 1712.20 SAR
Availability: InStock

Weight: 10.11 KG

1,713

2,446

(vat inclusive)

Hydraulic Cylinder

Split in 4 payments of 428.05 monthly without fees , learn more

Split it into 4 payments of 428.05 interest-free , learn more

Quantity

10+ In Stock

SKU C256C

12 Months Warranty

Lifting Tools Bottle Jack

Features

Aluminum bronze bearing reduces wear caused by off-center loads, mazimum spring force speeds piston retraction,
solid steel body for durability, chrome plated piston rod resists wear & corrosion, base mounting holes for positioning
Maximum sized springs speed piston return and increase spring life.
Solid steel cylinder body for durability Chrome plated piston rod resists wear and corrosion.

Stroke	6.250 in
Piston Rod Diameter	2.250 in
Series	Type / C-Series / General Purpose
Actuation	Single-Acting / Spring Return
Cylinder Capacity	25 ton
Oil Capacity	32.200 in3
Retracted Height	10.750 in
Extended Height	17.000 in
Effective Area	5.150 in2
Tons at 10000 psi	25.80 ton
Max Pressure	10000 psi
Bore Size	2.563 in
Base to Port	1.000 in
Outside Diameter	3.375 in
Bolt Circle Diameter	2.310 in
Number of Holes	2
Thread Size	1/2 – 13
Thread Depth	0.750 in
Collar Thread	3-5/16 – 12
Collar Thread Length	1.938 in
Piston Rod Internal Thread and Depth	1-1/2 – 16 x 7/8
Piston Rod Protrusion	0.375 in
Cylinder Material	Steel
Weight	22.30 lbs
Weight	10.11 KG
