-30% Out of Stock 3M Blue Male Disconnect, Nylon Insulation Type, 16 to 14 AWG Wire Range MNG14-250DMK

3M Blue Male Disconnect, Nylon Insulation Type, 16 to 14 AWG Wire Range MNG14-250DMK

Name: 3M Blue Male Disconnect, Nylon Insulation Type, 16 to 14 AWG Wire Range MNG14-250DMK
Brand: 3M
SKU: MNG14-250DMK
Price: 884.69 SAR
Availability: OutOfStock

Weight: 1.40 KG

885

1,264

(vat inclusive)

Blue Male Disconnect

Split in 4 payments of 221.17 monthly without fees , learn more

Split it into 4 payments of 221.17 interest-free , learn more

Quantity

Out of Stock

SKU MNG14-250DMK

Electrical Supplies

Download product Catalog

Features

The female disconnect attaches by slipping its tongue over the male tab.
Disconnecting is made quick and easy by the female part's rolled edges, which make a good holding force.
The nylon insulation provides a higher temperature rating.

Insulation	Partial
Insulation Type	Nylon
Insulation Color	Blue
Wire Range	16 to 14 AWG
Tab Size	0.032 in x 0.250 in
Barrel Inside Dia.	0.085 in
Max. Temp.	221 Degrees F
Max. Voltage	600 V
Overall Length	0.94 in
Seam	Brazed
Connection Material	Tin-Plated Brass
Standards	CSA Certified, RoHS Compliant, UL Listed
Connection Type	Crimp
Weight	1.40 KG
Code	BD-2JLK3
ID	1601054
